| Basic specification | |
| Engine model | Cummins 6CTA8.3-C190 |
| Rated power | 142KW@2200rpm |
| Dimension(L×W×H) | 8945×2600×3420（mm） |
| Operating weight(Standard) | 15600KG |
| Performance specification | |
| Travelling speed, forward | 6.5/11.4/14.6/24.8/30/49.2 |
| Travelling speed, reverse | 6.5/14.6/30 |
| Tractive force(f=0.75) | 80.2KN |
| Operating specification | |
| Max. steering angle of front wheels | 49 |
| Max. lean angle of front wheels | 17 |
| Max. oscillation angle of front axle | 16 |
| Max. oscillation angle of balance box | 13 |
| Frame articulation angle | 26 |
| Min. turning radius using articulation | 7.3m |
| Blade | |
| Maximum lift above ground | 450mm |
| Maximum grading depth | 535mm |
| Maximum blade position angle | 90° |
| Blade cutting angle | 29°~77° |
| Circle reversing rotation | 360° |
| Moldboard width × height | 4268×580mm |
