| Basic specification | |
| Engine model | Cummins 6BT5.9-C130 |
| Rated power | 97KW@2200rpm |
| Dimension(L×W×H) | 8290×2600×3465（mm） |
| Operating weight(Standard) | 12000KG |
| Performance specification | |
| Travelling speed, forward | 6.9/10.7/17.3/26/37.8/53.4 |
| Travelling speed, reverse | 6.9/17.3/37.8 |
| Tractive force(f=0.75) | 61.7KN |
| Operating specification | |
| Max. steering angle of front wheels | 49° |
| Max. lean angle of front wheels | 17° |
| Max. oscillation angle of front axle | 16° |
| Max. oscillation angle of balance box | 13° |
| Frame articulation angle | 26° |
| Min. turning radius using articulation | 6.6m |
| Blade | |
| Maximum lift above ground | 410mm |
| Maximum grading depth | 560mm |
| Maximum blade position angle | 90° |
| Blade cutting angle | 29°~77° |
| Circle reversing rotation | 360° |
| Moldboard width × height | 3658×580mm |
